Sany series original drilling rig -DR-80PRO model

YAHE MODEL
(12)
(18)
(43)
(44)
SANY series rotary drilling rig / Sany series original drilling rig -DR-80PRO model

Sany series original drilling rig -DR-80PRO model

Drilling Depth
5-20 m
Drilling Diameter
450-2200mm
Machine weight
14-16ton
Contact us Send Inquiry
Technical Specifications

Full Specifications

Model SANY DR-80PRO
Machine weight 16ton
Maxmum drilling depth 20m
Drilling diameter 350-2600mm
Engine brand ISUZU
Engine rated power 55KW
Maximum lifting force of main system 180KN
Maximum lifting force of auxiliary winch 13KN
Working status length*width*height 4500*2700*10000MM
Transport  status length*width*height 8500*2300*3200MM
Maximum torque of power head 80KN
Tail swing radius 2300MM
01

Autonomous driving

equipped with wireless radio and remote control driving system, easy to transition.

02

Construction safety

The cab is equipped with a comprehensive protective cover and can be fitted with a cab pedal.

03

Convenience

The rotary drive key bar is exposed for easy service and replacement; the main winching wire rope is fixed by a wedge, which is easy to disassemble and assemble. Some lubrication points are exposed for easy service.

04

After-Sales Support

Nationwide technical service network with one-year warranty and free professional training.
