Crawler type inter lock kelly bar rotary drilling rig DR-150 model

YAHE MODEL
(41)
(3)
Screenshot
Crawler type rotary drilling rig / Crawler type inter lock kelly bar rotary drilling rig DR-150 model

Crawler type inter lock kelly bar rotary drilling rig DR-150 model

Drilling depth
25-30m
Drilling diameter
500-1800mm
Engine power
151-176KW
Machine weight
30t
Contact us Send Inquiry
Model DR-150
Machine weight 30T
Maxmum drilling depth 30M
Drilling diameter 500-1800MM
Engine brand YUCHAI/WECHAI/CUMMINS(OPTIONAL)
Engine rated power 151-176KW
Maximum lifting force of main winch 150KN
Maximum lifting force of auxiliary winch 15KN
Working status length*width*height 7850*4000*13500MM
Transport  status length*width*height 11500*2800*3500MM
Maximum torque of power head 150KN.M
Tail swing radius 3950MM
01

New Design

New mast paired with new power box

02

Economy and fuel saving

powerful, reliable and durable, low fuel consumption and low operating cost.

03

Safe and comfortable:

reasonable layout, comfortable operation;Heavy mechanical suspension seat has good vibration reduction effect, avoid fatigue; air conditioner with high power, fearless of severe

04

cold and heat

enhanced top guardrail and extreme weather warning provide double protection.
